FEATURE:
Using single blade cut 2 rolls at the same time and
cut up to 150mm diameter rolls with 3" diameter shaft.
Suitable for adhesive and non-adhesive backed
products.
All functions controlled by a programmable Logical Controlled.
Hydraulic power supply for blade penetration.
The Moving Carriage using Ball Screw and Hardened Steel Ways.
Automatic Mandrel Support mounted for smaller shaft available.
Wide range of shafts from 1" to 30" diameter.
Blade penetration speed, Dwell time, log roll rotation speed are
adjustable on continuous rate.
|
MATERIALS
:
Industrial and Electrical
Adhesive tape, Packing, Non-Woven, From, rubber, Leather in roll.
|
SPECIFICATION:
| * |
Working
Width : |
| |
Standard :
1300mm
(Larger is optional extra) |
| * |
Outside
Diameter of Log : maximum 150mm on 3" shaft |
| * |
Slitting
Width : Minimum 3mm |
| * |
Power
Require : 220V x 50HZ x 3Phase or on request. |
| * |
Compressed
Air : 6 Bar |
| * |
Options
: Auto Knife Sharpener, Cutting Shaft, Shaft Sleeves. |
|
|
